Compact Load Cell TU Series 50 to 1000 Kg
Compact Load Cell TU Series 50 to 1000 Kg

The TU range of load Cell is designed for the measurement of static or dynamic loads in compression(output signal: negative) or traction (output signal: positive).
Manufacturer/Supplier of Load Cell: Intek Instruments, Delhi
All the transducers are calibrated in units of mass (Kg).
Capacity: 50 Kg to 1000 Kg.
This model has an IP67 protection degree so it can be used in aggressive atmospheres often found in the chemical industries.
The transducer body is machined from a single piece of stainless steel with no welding.
This means that load cell is highly resistant to mechanical shock and vibration.
The compact size means that these can be placed in positions that are difficult to access and where little space is available.



Send Inquiry



Main features of Compact TU Series Load Cell

  • Range of measurement: from 50 to 1000 kg
  • Accuracy class: 0,2%
  • All stainless steel construction
  • Corrosion resistant
  • Grade of protection: IP67 ( norme DIN 40050)
  • Compact size


Technical Specification of Compact Load Cell

Accuracy 0,2%
Nominal full scale load (Ln)50 - 1000 kg
Nominal output at FSO2mV/V
Output tolerance at Ln<± 0,2% FSO
Combined errors: Non linearityHisteresis, Repeatibility< ± 0,2% FSO
Creep (after 30 min. at Ln)< ± 0,06% FSO
Zero load out of balance signal< ± 1% FSO
Thermal drift in Sensitivity compensated Zero range Calibration< ± 0,01% FSO°C
< ± 0,01% FSO°C
Nominal input resistance350 Ohm
Nominal output resistance350 Ohm
Isolation resistance> 10 GOhm
Nominal supply voltage10 V
Maximum supply voltage15 V
Compensated temperature range-10 to +50°C
Maximum temperature range-20 to +60°C
Storage temperature range-30 to +80°C
Permitted static load130% Ln
Permitted dinamic load100% Ln
Maximum applicable load150% Ln
Rupture load> 300% Ln
Maximum elastic deformation at Ln< 0,2 mm
Grade of protection (DIN40050)IP67
Electrical connections screened cable4x0,25 / 5 m.
Elastic element materialStainless steel
Supplier of Load CellIntek Instruments, Delhi
